S Series: TRIMAX
3 Plunger Pumps

The S Series Trimax 3 plunger pumps are designed to provide a safe, reliable supply of high-pressure water-based fluids for mining and heavy industrial applications.

Core Values

Lowest Installed Cost

LOWER
INSTALLED
COST

LEARN MORE

Lowest Operating Cost

LOWEST
OPERATING
COST

LEARN MORE

Lowest Risk

REDUCED
PROJECT
RISK

LEARN MORE

Benefits

High Energy Efficiency

Variable speed controls using demand-based operation

High Performance

Power ratings up to 375hp.
Proven volumetric efficiencies up to 98%.
Fluid end components designed with Computational Fluid Dynamics to maximise efficiency.

Maximum Reliability

Designed for continuous duty, 24/7

Extended Operational Life

smooth pressure profile, reduces wear and tear on system components (hoses, seals, valves) caused by destructive pressure surges

Compact Footprint

Compact horizontal 3 plunger design

Technical Data

Application

Longwall Coal Mining and Industrial manufacturing applications including forging, extrusion, rolling, hydrostatics, power generation, industrial cleaning and filtration.

Description

Skid-mounted horizontal three plunger design pumping unit. High-efficiency energy through demand-based control. Remote active performance management through internet to sustain reliability and performance throughout the life of the pump.

Materials

Valves: High grade stainless steel for maximum life.
Valve Chest: High grade stainless steel or E.N.P carbon steel.
Plungers: High purity ceramic plungers or tungsten carbide rams.
Bearings: Spherical roller main journals with lead bronze small and big ends.
Valve Lifters: Fitted as an optional, for safe pressure control.
Unloading Valve: Fitted as an optional, for safe flow diversion. (ATEX, IECEx, MA)
Gland Packing: Self-adjusting spring-loaded Kevlar packing, for maximum sealing
